| speicifications | HTMC800S |
| Max. turning diameter on bed(mm) | 600 |
| Max. cutting length(mm) | 1200 |
| Max. cutting diameter(mm) | 580 |
| Spindle nose type | A2-8(6) |
| Main shaft hole diameter(mm) | 85/67 |
| Spindle speed range（r/min） | 3000 |
| Sub-Spindle speed range（r/min） | 4000 |
| Spindle motor power（KW） | 37 |
| Sub-Spindle motor power（KW） | 30 |
| X/Y/Z-axis fast movement speed(mm) | 12/12/12 |
| X-axis travel(mm) | 720 |
| Z-axis travel(mm) | 1550 |
| Y-axis travel(mm) | ±125 |
| Standard knife holder form | 12 station power knife tower |
| machine size (mm) | 5020L*3070W*2925H |
| Machine weight (KG) | 17000 |
China's largest turning-milling composite production base.
