| speicifications | TCK600Y | TCK600SY |
| Max. turning diameter on bed(mm) | 600 | 600 |
| Max. cutting length(mm) | 500 | 500 |
| Max. cutting diameter(mm) | 460 | 350 |
| Spindle nose type | A2-6 | A2-6 （5） |
| Main shaft hole diameter(mm) | 65 | 56 |
| Spindle speed range（r/min） | 4500 | 4500 |
| Sub-spindle speed range（r/min） | - | 5000 |
| Spindle motor power（KW） | 30 | 30 |
| Sub-spindle power (KW) | 11 | 11 |
| X-axis travel(mm) | 280 | 280 |
| Z-axis travel(mm) | 550 | 550 |
| Y-axis travel(mm) | ±50 | ±50 |
| Standard knife holder form | 12 station power knife tower | 12 station power knife tower |
| machine size (mm) | 3280L*2085W*2440H | 2790L*1900W*1850H |
| Machine weight (KG) | 4500 | 4800 |
China's largest turning-milling composite production base.
