| speicifications | HMC1075 |
| Table size （mm） | 1300×600 |
| Max. worktable load（kg） | 800 |
| T-slot (number*width*distance) | 5-18-100 |
| X-axis travel(mm) | 1000 |
| Y-axis travel(mm) | 750 |
| Z-axis travel(mm) | 800 |
| X-axis Fast shift speed(m/min) | 24 |
| Y-axis Fast shift speed(m/min) | 12 |
| Z-axis Fast shift speed(m/min) | 24 |
| Spindle taper hole | BT40Φ150 |
| Spindle speed (rpm) | 6000 |
| machine size (mm) | 3700L*3050W*2700H |
| Machine weight (KG) | 8000 |
